Hårdvaruspecifikation
Formfaktor
Rackmonterbar, Skrivbordsmodell
Ethernettyp
Gigabit Ethernet
Nätverksportar typ
10/100/1000
Övriga portar typ
SFP (mini-GBIC)
Gränssnitt
1 x hantering (Gigabit LAN) RJ-45 hantering, 1 x hantering (mini-USB) Type B hantering, 1 x seriell (konsol) RJ-45 hantering, 1 x USB Type A, 4 x 1000Base-X SFP upplänk, 48 x 1000Base-T RJ-45
Expansionskortplatser
1 (totalt)/ 1 (ledig) x Plats för stackmodul
Funktioner & protokoll
Funktioner
BGP-4, EIGRP for IPv6, IS-IS, OSPFv3, PBR (policy-based routing), PIM-DM, PIM-SM, PIM-SSM, RIP-1, RIP-2, RIPng, Statisk IP-routing, ARP-stöd, DHCP-snooping, Dynamic ARP Inspection (DAI), Energy Efficient Ethernet, Flaktlos, Flexible NetFlow (FNF), IGMP snooping, LACP (Link Aggregation Control Protocol), MLD-snooping, Nivå 2-växling, Quality of Service (QoS), RADIUS-stöd, Rapid Per-VLAN Spanning Tree Plus (PVRST+), Remote Switch Port Analyzer (RSPAN), Stöd för Access Control List (ACL), Stöd för IPv6, Stöd för MSTP (Multiple Spanning Tree Protocol), Stöd för Port Aggregation Protocol (PAgP), Stöd för RSTP (Rapid Spanning Tree Protocol), Uni-Directional Link Detection (UDLD), Virtual Route Forwarding-Lite (VRF-Lite), VLAN-stöd
Administrationsprotokoll
CLI, RMON 1, RMON 2, RMON 3, RMON 9, SNMP 1, SNMP 2c, SNMP 3, SSH, Telnet
Standarder
IEEE 802.1ab (LLDP), IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad (LACP), IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Märkning
BSMI CNS 13438 Class A, CISPR 22 klass A, CISPR 24, CSA C22.2 No. 60950-1 Second Edition, EN 60950-1 Second Edition, EN 61000-3-2, EN 61000-3-3, EN55022 klass A, EN55024, FCC Part 15 A, GOST, ICES-003 klass A, IEC 60950-1 Second Edition, ISO 7779, KCC, KN22 Class A, KN24, NOM, RoHS, UL 60950-1 Second Edition, VCCI Class A
Jumbo Frame-support
9198 byte
MAC Address Table Size
32 000 poster, IPv4-routes: 24000, NetFlow-poster: 48000, Switchade virturlla gränssnitt (SVIs): 1000, Virtuella gränssnitt (VLAN): 4000
