Användning
Max driftstemperatur
50 °C
Min förvaringstemperatur
-20 °C
Max förvaringstemperatur
70 °C
Luftfuktighet vid drift
90 % (icke kondenserande)
Luftfuktighet vid lagring
95 % (icke kondenserande)
Rackmonteringssats
Inkluderat
Statusindikatorer
Länk/akvititet, PoE, Portöverföringshastighet
MTBF (genomsnittstid mellan fel)
1,737,411 h
Funktioner & protokoll
Funktioner
Statisk IP-routing, 1,5 MB paketbuffert, 2 fläktar, Auto VoIP, Broadcast Storm Control, Denial of Service (DoS) protection, DHCP-klient, DHCP-relä, DHCP-snooping, DHCP-stöd, DSCP-support (DiffServ Code Point), Dynamic ARP Inspection (DAI), GARP VLAN Registration Protocol (GVRP), Generic Attribute Registration Protocol (GARP), Guest VLAN, ICMP Router Discovery Protocol (IRDP), IGMP snooping, IGMP-förfrågningar, Kabeltest, LACP (Link Aggregation Control Protocol), Lagra och vidarebefordra, MAC-låsning, MLD-snooping, Multicast Storm Control, Multicast VLAN Registration (MVR), Portspegling, Private VLAN, Quality of Service (QoS), SNTP-support, Stöd för DiffServ, Syslog-stöd, Type of Service (ToS), Unicast Storm Control, Voice VLAN, WRR (weighted round robin)
Administrationsprotokoll
HTTP, HTTPS, RMON 1, RMON 2, RMON 3, RMON 9, SNMP 1, SNMP 2c, SNMP 3, TFTP
Standarder
IEEE 802.1ab (LLDP), IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad (LACP), IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Märkning
AN/NZS 60950.1:2015, ANSI C63.4-2014, AS/NZS CISPR22:2009+A1:2010 Class A, CB, CCC, CSA 22.2 No. 950, C-Tick Class A, EN 55022/CISPR 22 Class A, EN 60950, EN55024, FCC CFR47 Part 15 B Class A, FCC Part 15 A, ICES-003:2016 issue 6 Class A, IEC 60950-1:2005 (ed.2)+A1:2009+A2:2013, IEC 950, VCCI Class A
MAC Address Table Size
16K poster, ACL: 100, ARP-poster: 512, IGMP multicastgrupper: 512, IPv4-routes (statisk): 32, IPv6-routes (statisk): 32, VLAN-stöd: 256
