Cisco Meraki MR74 Cloud Managed

CiscoMeraki MR74 Cloud Managed

12 495 kr
Frakt från 139 kr
Hyr från 395 kr/månad i 36 månader
Cisco artikelnr. MR74-HW
Dustin artikelnr. 5011035630

Snabbfakta

  • Tillverkare
    Cisco Meraki
  • Trådlösa standarder
    802.11a/b/g/n/ac Wave 2, Bluetooth 4.0 LE
  • Dataöverföringshastighet
    1300 Mbps
  • WiFi-frekvensband
    2.4 GHz
  • Formfaktor
    Extern
Ideal use cases
Harsh, industrial, and outdoor environments
Voice, video, and performance-intensive networks

Hardware features
IP67 rated: tested for dust, shock, vibration, and moisture
4 radios: 2.4 GHz, 5 GHz, dual-band WIDS/WIPS, and Bluetooth BLE
2-stream 802.11ac Wave 2 MU-MIMO and 802.11n, up to 1.3 Gbps
Gigabit Ethernet port, 802.3af PoE compatible

Cloud management
Network-wide visibility and control
Self-provisioning for rapid deployment
Automatic reporting
Seamless firmware updates

Enterprise security
802.1X and native Active Directory integration
Air Marshal: real-time WIPS with forensics
Stateful Layer 3-7 firewall
Identity-based group policies
Built-in antivirus scan (NAC)

Guest access
1-click secure guest access
Guest isolation firewall
Customizable splash pages
Integrated Facebook WiFi login

RF optimization
Cloud-based RF planning
Built-in spectrum analysis
Dual-concurrent radios with band steering

Layer 7 traffic shaping
Classifies hundreds of applications
Create per-application bandwidth limits
Prioritize productivity apps
Restrict recreational traffic

Location Analytics
Measure visitor capture rate, visit length, and repeat visit rate
Measure visitor trends over time and compare performance across locations
Enable location services through integrated iBeacon functionality

Device management
Create device-specific firewall rules
Deploy applications and updates
Troubleshoot issues with built-in RDP

Mesh
Self-configuring, self-optimizing mesh
High performance multi-radio routing protocols
Extends coverage to hard-to-wire areas
Self-heals after cable or switch failures

Specifikation Meraki MR74 Cloud Managed

Allmänt

Tillverkare
Cisco Meraki
Modell
MR74 Cloud Managed
Produkttyp
Trådlös accesspunkt

Nätverk

Trådlösa standarder
802.11a/b/g/n/ac Wave 2, Bluetooth 4.0 LE
WiFi-frekvensband
2.4 GHz
Dataöverföringshastighet
1300 Mbps
Linjekodningsformat
256 QAM

Hårdvaruspecifikation

Formfaktor
Extern
Anslutningsteknik
Trådlös
Robust design
Utomhus
Gränssnitt
1 x 1000Base-T (PoE) - RJ-45, 4 x antenn - N connector
Datalänkprotokoll
Bluetooth 4.0 LE, IEEE 802.11a, IEEE 802.11ac Wave 2, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Strömförsörjningstyp
PoE
Energiförbrukning
11 W
Statusindikatorer
Status

Användning

Nätverksprotokoll
IPSec
Funktioner
2T2R MIMO-teknik, 802.1x-autentisering, Bluetooth Low Energy Beaconing, DSCP-support (DiffServ Code Point), Maximum Ratio Combining (MRC), MU-MIMO-teknik, Quality of Service (QoS), Stråleformingsteknologi, SU-MIMO-teknologi, Unscheduled Automatic Power Save Delivery (U-APSD), Wireless Intrusion Detection System (WIDS), Wireless Intrusion Prevention System (WIPS), IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11r, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1x, IEEE 802.3af, IP67, Plug and Play, IEEE 802.11ac Wave 2
Min temperatur vid drift
-40 °C
Max temperatur vid drift
55 °C

Säkerhet

Krypteringsalgoritm
AES, TKIP, TLS, TTLS, WEP, WPA, WPA2-Enterprise, WPA2-PSK
Verifieringsprotokoll
EAP-SIM, Extensible Authentication Protocol (EAP), MS-CHAP v.2, Radio Service Set ID (SSID)

Dimensioner & Vikt

Bredd
25.6 cm
Djup
6.5 cm
Höjd
15.8 cm
Vikt
1090 g

Garanti

Garanti
Begränsad garanti - 1 år, 1 års garanti
Det finns inga tillbehör för denna produkt.

Dokument Meraki MR74 Cloud Managed
