Noctua NF-A14 PWM

140 mm

  • Lagerstatus: Skickas omgående 6 kvar
  • Frakt från: 139 kr
  • Artikelnr.
  • 5010809694
  • Tillv. art. nr.
  • NF-A14 PWM


140 mm
300-1500 rpm
4-pin fläktanslutning


  • Square 140 mm frame
  • Flow acceleration channels
  • AAO frame
  • Stepped Inlet design
  • Inner surface microstructures
  • Integrated anti-vibration pads
  • SSO2 bearing


  • Metal bearing shell
  • Low-Noise Adaptor


The NF-A14 is a premium quality quiet 140 mm fan with a square frame that complies with Noctua's AAO (Advanced Acoustic Optimization) standard. Its square shape and 140 mm mounting holes make it ideal for use on water-cooling radiators or as an upgrade for 140 mm case fans. Featuring sophisticated aerodynamic design measures such as flow acceleration channels, the NF-A14 further improves the renowned quiet cooling performance of the award-winning NF-P14. The PWM version sports Noctua's custom designed NE-FD1 IC for fully automatic speed control via 4-pin fan headers and comes with a low-noise-adaptor to reduce the maximum speed during PWM control from 1500 rpm to 1200 rpm. Its performance-oriented 1500 rpm top speed and comprehensive speed control options make the NF-A14 PWM an elite choice for users who strive to strike a perfect balance between excellent cooling capacity and superb quietness of operation, be it on water-cooling radiators, on heatsinks or in case ventilation.


Tillverkare Noctua
Förpackad kvantitet 1
Monteringskit Inkluderat
MTBF 150,000 hour(s)
Standarder som följs
Kompatibel standard RoHS
Kylfläns och fläkt
Fläktdiameter 140 mm
Rotationshastighet 300-1500 rpm
Strömkontakt 4-pin fläktanslutning
Fläkthöjd 25 mm
Fläktlager SSO2-lager
Ljudnivå 13.8 - 19.2 dBA
Luftflöde 82.5 cfm
Lufttryck 0.89-1.51 mm
Heatsink & Fan
Features Pulse-width modulation (PWM) support, Advanced Acoustic Optimisation (AAO), flow acceleration channels
Service och support
Service & support 6 års garanti
